Description:

For established gardens, our ALL-NEW front-tine tiller has all the muscle you need for working garden beds into a loose, rich mix. Variable tilling width makes this a versatile choice.

Features:

• Power Driven Wheels: The tractor style pneumatic tires propel the tiller forward easily in almost any terrain. The wheels can be released with a pin for free-wheeling when needed to travel or maneuver the tiller.
• Counter Rotating Tines (CRT): The tines rotate in opposition to the powered wheels, creating an aggressive tilling action. This helps hold the tiller back, preventing it from leap-frogging forward during heavier uses, like sod-busting or deep tilling in heavy clay soil.
• Drag Stake and Debris Shield: The drag stake provides extra resistance. When not needed, it can be raised and pinned in place. The debris shield protects operator from thrown soil.
• Powerful Engine: Easy-starting, OHV engine has 10.2 ft-lbs gross torque (209cc). 3700 RPM and cast iron cylinder sleeve. Warranted for 2 years (90 days in commercial use).

Specifications:

Engine

• Air Filter: Paper
• Cooling Methods: Air
• Displacement: 209 cc
• Engine Type: OHV
• Lubrication: Splash
• Make: DR1
• Number Of Cylinders: 1
• Oil Capacity: 18.5 oz
• Oil Type: 30HD/10W-30
• RPM Speeds: 3700
• Starting Type: Recoil

Wheels Tires

• Number of Tires: 2
• Tire Size: 13" x 5"

Warranty

• Engine Warranty: 2 yrs residential use, 90 days commercial
• Machine Warranty: 2 yrs residential use, 90 days commercial

Dimensions

• Height: 48"
• Length: 56"
• Shipping Weight: 157 lbs
• Weight: 145 lbs
• Shipping Dimensions: 43" x 20" x 24"

Fuel System

• Fuel Capacity: 3.6 qts

General

• Assembly: Some assembly needed
• Transmission: Geared
• Engine Type: OHV (Overhead Valve)
• Displacement: 209 cc
• Transmission: Geared
• Fuel Tank Capacity: 3.6 quarts (≈ 0.9 gallons / 3.4 L)
• Weight: 145 lbs (65.8 kg)
